FLOOR MOUNTS AND VIBRATION DAMPING
ZEUS HIGH ARTICULATED anti-vibration foot in vulcanised rubber SBR
More details
Features
- Anti-vibration device included
- Made of SBR recycled volcanic rubber
- Height adjustment ring nut min 150 max 205 mm (model Short)
- Height adjustment ring nut min 200 max 255 mm (model Long)
- Non-slip knurling adjustment
- Adjustable Joint
- No. 2 seats for spirit level insertion
- Fixing screw M8 x 50
- Inclination 0-15°
Models
Cod.: SCD500279
VULCANIZED RUBBER FLOOR SUPPORT - ADJUSTABLE AND ARTICULATED - "ZEUS" H.70 SHORT (PACK OF 4 PCS)
- H [mm] 150/205
- L [mm] 60
- Ø [mm] 160
- Load capacity [kg] 500
Cod.: SCD500280
VULCANIZED RUBBER FLOOR SUPPORT - ADJUSTABLE AND ARTICULATED - "ZEUS" H.100 LONG (PACK OF 4 PCS)
- H [mm] 200/255
- L [mm] 60
- Ø [mm] 160
- Load capacity [kg] 500
